TIRE SAFETY CAGE 5 BAR 36005 ASCOT
Return to Tire & Wheel Service Products
Protect your shop technicians and remain fully compliant with federal safety laws with the Ken-Tool T105 5-Bar Tire Inflation Safety Cage. Engineered for high-volume commercial garages, fleet service centers, and heavy equipment operations, this heavy-duty cage serves as your frontline defense against catastrophic tire explosions, blown lock rings, and rim failures.
Crafted in the USA from heavy-gauge structural steel, the T105 provides ultimate containment during high-pressure inflation, ensuring peace of mind when servicing large commercial transport and OTR assemblies.
Key Features & Benefits
- OSHA Certified Protection: Mandated by safety regulations, this cage fully meets and exceeds OSHA Regulation 29-CFR Part 1910.177 standards for servicing tubeless and multi-piece commercial rims.
- Heavy-Duty Construction: Built from 2-1/4" (5.7 cm) structural steel tubing arc-welded to a solid, heavy-plate steel base for maximum structural integrity under extreme force.
- Advanced Safety Design: Features an open-front roll-in design for easy tire placement, backed by solid vertical steel reinforcement straps to prevent high-impact roll-through or blowouts.
- High-Pressure Rated: Rigorously designed and certified to safely handle maximum inflation pressures up to 130 PSI.
- Wide Vehicle Compatibility: Optimally sized to accommodate Super Singles, wide radial truck tires, medium/heavy-duty transport, agricultural tractor tires, and small OTR assemblies.
Technical Specifications
- Brand: Ken-Tool
- Model Number: 36005 (T105)
- Configuration: 5-Bar Design
- Maximum Pressure: 130 PSI
- Base Dimensions: 41" L x 26" W (104 cm x 66 cm)
- Inside Width: 20-1/2" (52 cm)
- Inside Bend Height: 43-1/2" (110.5 cm)
- Total Weight: Approx. 142 lbs (64.4 kg)
- Country of Origin: USA
Out of Stock
T105
191.0
