The WH4426 Swivel Valve is a premium, heavy-duty large bore straight swivel valve engineered for high-efficiency tire inflation and maintenance. Built specifically for demanding commercial and industrial environments, this 26-inch valve ensures a secure, leak-free connection while allowing fluid rotational movement to prevent hose twisting and strain during service.
It is ideal for heavy-duty trucks, Off-The-Road (OTR) mining and construction vehicles, and large agricultural machinery.

Key Features

• Swivel Design: Maximizes flexibility and prevents hose kinking by allowing the valve to rotate smoothly under pressure.
• Large Bore Construction: Delivers high-flow capacity for significantly faster inflation and deflation times on high-volume tires.
• Straight Configuration: Offers direct, unbent access for straightforward servicing in standard wheel assemblies.
• Heavy-Duty Durability: Manufactured from high-grade, corrosion-resistant materials to withstand harsh field environments and extreme operating pressures.

• Model: WH4426
• Type: Large Bore Swivel Valve
• Bend: Straight (0°)
• Length: 6.00 inches (152.4 mm)
• Weight: 0.15 lbs (0.07 kg)
• Compatibility: Fits standard large bore rim spuds and inflation equipment

• Specifications
